GXL, SXL, and TXL Automotive Wire

Home » Wire & Cable » Hook-up & Lead Wire » Automotive » GXL

Product Details

Available in Stranded Bare Copper
XLPE (Cross-linked Polyethylene) Insulation, 125°C, 60V
J1128, GXL Ford ESB-M1L85-B/Chrysler MS-8900
Exceptions: SXL Ford ESB-M1L85-A/Chrysler MS-5919, TXL Ford ESB-M1L123-A/Chrysler MS-8288
Click here for additional product information.

Showing all 23 results

Part Number	Construction	Insulation	Insulation (in)	Nom. OD (in)	Temp.	Volt.	Product Type	Add To RFQ Cart
947	20 (7x28) BC	XLPE	.023	.086	125	60	GXL	Add ( Color ) ( Feet ) Add Continue Browsing
948	18 (16X30) BC	XLPE	.023	.094	125	60	GXL	Add ( Color ) ( Feet ) Add Continue Browsing
949	16 (19x29) BC	XLPE	.023	.105	125	60	GXL	Add ( Color ) ( Feet ) Add Continue Browsing
950	14 (19x27) BC	XLPE	.023	.119	125	60	GXL	Add ( Color ) ( Feet ) Add Continue Browsing
951	12 (19x25) BC	XLPE	.026	.145	125	60	GXL	Add ( Color ) ( Feet ) Add Continue Browsing
952	10 (19x23) BC	XLPE	.031	.181	125	60	GXL	Add ( Color ) ( Feet ) Add Continue Browsing
953	8 (19x.0285) BC	XLPE	.037	.216	125	60	GXL	Add ( Color ) ( Feet ) Add Continue Browsing
942	18 (16X30) BC	XLPE	.030	.110	125	60	SXL	Add ( Color ) ( Feet ) Add Continue Browsing
943	16 (19x29) BC	XLPE	.032	.118	125	60	SXL	Add ( Color ) ( Feet ) Add Continue Browsing
944	14 (19x27) BC	XLPE	.035	.138	125	60	SXL	Add ( Color ) ( Feet ) Add Continue Browsing
945	12 (19x25) BC	XLPE	.037	.162	125	60	SXL	Add ( Color ) ( Feet ) Add Continue Browsing
946	10 (19x23) BC	XLPE	.041	.185	125	60	SXL	Add ( Color ) ( Feet ) Add Continue Browsing
SXL819B	8 (19x.0285) BC	XLPE	.043	.234	125	60	SXL	Add ( Color ) ( Feet ) Add Continue Browsing
941	20 (7x28) BC	XLPE	.030	.096	125	60	SXL	Add ( Color ) ( Feet ) Add Continue Browsing
954	22 (7x30) BC	XLPE	.016	.062	125	60	TXL	Add ( Color ) ( Feet ) Add Continue Browsing
955	20 (7x28) BC	XLPE	.016	.070	125	60	TXL	Add ( Color ) ( Feet ) Add Continue Browsing
956	18 (16X30) BC	XLPE	.016	.078	125	60	TXL	Add ( Color ) ( Feet ) Add Continue Browsing
957	16 (19x29) BC	XLPE	.016	.089	125	60	TXL	Add ( Color ) ( Feet ) Add Continue Browsing
958	14 (19x27) BC	XLPE	.016	.102	125	60	TXL	Add ( Color ) ( Feet ) Add Continue Browsing
959	12 (19x25) BC	XLPE	.018	.130	125	60	TXL	Add ( Color ) ( Feet ) Add Continue Browsing
TXL819B	8 (19x.0285) BC	XLPE	.022	.192	125	60	TXL	Add ( Color ) ( Feet ) Add Continue Browsing
960	10 (19x23) BC	XLPE	.020	.160	125	60	TXL	Add ( Color ) ( Feet ) Add Continue Browsing
939	24 (7X32) BC	XLPE	.016	.056	125	60	TXL	Add ( Color ) ( Feet ) Add Continue Browsing

Packaging:

Available on reels 25′ or greater, minimum order quantity may apply
Available in drums and bulk reels
Hook-up/Lead Wire kits available upon request

Color Code:

0: Black
1: Brown
2: Red
3: Orange
4: Yellow

5: Green
6: Blue
7: Violet
8: Gray
9: White

Custom colors and striping available upon request.

Applications:

Automobile, boat, trailer point-to-point wiring

No. Of Cond.	Color	No. Of Cond.	Color	No. Of Cond.	Color
1	Black	2	White	3	Red
4	Green	5	Orange	6	Blue
7	White/Black	8	Red/Black	9	Green/Black
10	Orange/Black	11	Blue/Black	12	Black/White
13	Red/White	14	Green/White	15	Blue/White
16	Black/Red	17	White/Red	18	Orange/Red
19	Blue/Red	20	Red/Green	21	Orange/Green
22	Black/White/Red	23	White/Black/Red	24	Red/Black/White
25	Green/Black/White	26	Orange/Black/White	27	Blue/Black/White
28	Black/Red/Green	29	White/Red/Green	30	Red/Black/Green
31	Green/Black/Orange	32	Orange/Black/Green	33	Blue/White/Orange
34	Black/White/Orange	35	White/Red/Orange	36	Orange/White/Blue
37	White/Red/Blue	38	Black/White/Green	39	White/Black/Green
40	Red/White/Green	41	Green/White/Blue	42	Orange/Red/Green
43	Blue/Red/Green	44	Black/White/Blue	45	White/Black/Blue
46	Red/White/Blue	47	Green/Orange/Red	48	Orange/Red/Blue
49	Blue/Red/Orange	50	Black/Orange/Red	51	White/Black/Orange
52	Red/Orange/Black	53	Green/Red/Blue	54	Orange/Black/Blue
55	Blue/Black/Orange	56	Black/Orange/Green	57	White/Orange/Green
58	Red/Orange/Green	59	Green/Black/Blue	60	Orange/Green/Blue

No. Of Cond.	Color	No. Of Cond.	Color	No. Of Cond.	Color
1	Black prd with Red	2	Black prd with White	3	Black prd with Green
4	Black prd with Blue	5	Black prd with Yellow	6	Black prd with Brown
7	Black prd with Orange	8	Red prd with White	9	Red prd with Green
10	Red prd with Blue	11	Red prd with Yellow	12	Red prd with Brown
13	Red prd with Orange	14	Green prd with Blue	15	Green prd with White
16	Green prd with Brown	17	Green prd with Orange	18	Green prd with Yellow
19	White prd with Blue	20	White prd with Brown	21	White prd with Orange
22	White prd with Yellow	23	Blue prd with Brown	24	Blue prd with Orange
25	Blue prd with Yellow	26	Brown prd with Orange	27	Brown prd with Yellow
28	Purple prd with Red	29	Purple prd with White	30	Purple prd with Green
31	Purple prd with Blue	32	Purple prd with Brown	33	Purple prd with Yellow
34	Purple prd with Orange	35	Purple prd with Slate	36	Purple prd with Black
37	Slate prd with Red	38	Slate prd with White	39	Slate prd with Green
40	Slate prd with Blue	41	Slate prd with Brown	42	Slate prd with Yellow
43	Slate prd with Orange	44	Slate prd with Black	45	White/Black prd with Red
46	White/Black prd with Green	47	White/Black prd with Blue	48	White/Black prd with Brown
49	White/Black prd with Yellow	50	White/Black prd with Orange	51	White/Black prd with Purple

No. Of Cond.	Color	No. Of Cond.	Color	No. Of Cond.	Color
1	Black	2	Red	3	Brown
4	Blue	5	Orange	6	Yellow
7	Purple	8	Pink	9	Tan
10	Black/Red	11	Black/Brown	12	Black/Blue
13	Black/Orange	14	Black/Yellow	15	Red/Brown
16	Red/Blue	17	Red/Orange	18	Red/Yellow
19	Brown/Blue	20	Brown/Orange

No. Of Cond.	Color	No. Of Cond.	Color	No. Of Cond.	Color
1	Black	2	Red	3	Blue
4	Orange	5	Yellow	6	Brown
7	Red/Black	8	Blue/Black	9	Orange/Black
10	Yellow/Black	11	Brown/Black	12	Black/Red
13	Blue/Red	14	Orange/Red	15	Yellow/Red
16	Brown/Red	17	Black/Blue	18	Red/Blue
19	Orange/Blue	20	Yellow/Blue	21	Brown/Blue
22	Black/Orange	23	Red/Orange	24	Blue/Orange
25	Yellow/Orange	26	Brown/Orange	27	Black/Yellow
28	Red/Yellow	29	Blue/Yellow	30	Orange/Yellow
31	Brown/Yellow	32	Black/Brown	33	Red/Brown
34	Blue/Brown	35	Orange/Brown	36	Yellow/Brown
37	Black/Brown

No. Of Cond.	Color	No. Of Cond.	Color	No. Of Cond.	Color
1	White/Blue prd with Blue/White	2	White/Orange prd with Orange/White	3	White/Green prd with Green/White
4	White/Brown prd with Brown/White	5	White/Gray prd with Gray/White	6	Red/Blue prd with Blue/Red
7	Red/Orange prd with Orange/Red	8	Red/Green prd with Green/Red	9	Red/Brown prd with Brown/Red
10	Red/Gray prd with Gray/Red	11	Black/Blue prd with Blue/Black	12	Black/Orange prd with Orange/Black
13	Black/Green prd with Green/Black	14	Black/Brown prd with Brown/Black	15	Black/Gray prd with Gray/Black
16	Yellow/Blue prd with Blue/Yellow	17	Yellow/Orange prd with Orange/Yellow	18	Yellow/Green prd with Green/Yellow
19	Yellow/Brown prd with Brown/Yellow	20	Yellow/Gray prd with Gray/Yellow	21	Purple/Blue prd with Blue/Purple
22	Purple/Orange prd with Orange/Purple	23	Purple/Green prd with Green/Purple	24	Purple/Brown prd with Brown/Purple
25	Purple/Gray prd with Gray/Purple

No. Of Cond.	Color	No. Of Cond.	Color	No. Of Cond.	Color
1	Black	2	Brown	3	Red
4	Orange	5	Yellow	6	Green
7	Blue	8	Violet	9	Gray
10	White	11	White/Black	12	White/Brown
13	White/Red	14	White/Orange	15	White/Yellow
16	White/Green	17	White/Blue	18	White/Violet
19	White/Gray	20	White/Black/Brown	21	White/Black/Red
22	White/Black/Orange	23	White/Black/Yellow	24	White/Black/Green
25	White/Black/Blue	26	White/Black/Violet	27	White/Black/Gray
28	White/Brown/Red	29	White/Brown/Orange	30	White/Brown/Yellow
31	White/Brown/Green	32	White/Brown/Blue	33	White/Brown/Violet
34	White/Brown/Gray	35	White/Red/Orange	36	White/Red/Yellow
37	White/Red/Green	38	White/Red/Blue	39	White/Red/Violet
40	White/Red/Gray	41	White/Orange/Yellow	42	White/Orange/Green
43	White/Orange/Blue	44	White/Orange/Violet	45	White/Orange/Gray
46	White/Yellow/Green	47	White/Yellow/Blue	48	White/Yellow/Violet
49	White/Yellow/Gray	50	White/Green/Blue	51	White/Green/Violet
52	White/Green/Gray	53	White/Blue/Violet	54	White/Blue/Gray
55	White/Violet/Gray	56	White/Black/Brown/Red	57	White/Black/Brown/Orange
58	White/Black/Brown/Yellow	59	White/Black/Brown/Green	60	White/Black/Brown/Blue
